Rapid growth in digital flexible packaging with a field-proven solution, this on-demand, mid-web sustainable press helps generate high margins by winning jobs that are not typically profitable through conventional production and Optimize and control production increase press usage with cutting edge RIP capabilities, and expand fleet connectivity, by utilizing a powerful, scalable and cloud connected server. Enables easy, on-demand treatment of virtually any substrate.
Unleast the performance of your HP Indigo press with a suite of solutions that enables you to create your Print Factory of the future.
Enable your operator to get the most out of your press by building his self-sufficiency through knowledge, and on-press platform and expert support.
Lead, innovate, and create distinct and incredible products for your customers with the most diverse media on hand.
Apply never-before-seen adaptive security solutions that provide multi-layered digital protection in just one pass.
Step right into the forefront by exceeding your customers’ demands and lead a new era of responsible printing
Meet the experts and solve your most challenging jobs. Experience a live one-on-one demo tailored for you with our Application Engineers.
TECHNICAL SPECIFICATIONS
Printing speed
101 ft./min (31 m/min) in 4-color mode; 138 ft./min (42 m/min ) in EPM; 82 ft./ min (25 m/min ) in 5-color mode
Image resolution
812 dpi at 8 bit; address-ability: 2438 x 2438 dpi HDI (High Definition Imaging)
Line screens
175, 180, 180m, HMF-200
Image size
29.37 in x 44.09 in (746 x 1120 mm) maximum; Repeat length: 21.65 in (550 mm) minimum; 44.09 in (1120 mm) maximum
Substrate thickness
0.4 mil to 16 mil/ 0.4pt to 16pt (10 to 400 microns)
Substrate type
Film (PET, BOPP, PE, BOPA), shrink film (PETG, PVC, OPS) label stock (PE label), pre-laminates (PET/ALU/PE) and paper
Web width
Maximum width: 30 in (762 mm); Minimum width: 15.75 in (400 mm)
Priming unwinder
Max roll diameter: 39.37 in (1000 mm)Max roll weight: 1876 lb (850 kg)Core inside diameter:• Standard 3 in• Standard 6 in adapter
Rewinder
Maximum roll diameter: 31.5 in (800 mm)Maximum roll weight: 1545 lb (700 kg)
Print server
HP Production Pro for Indigo Labels & Packaging
Press dimensions
Width: 383 in (9730 mm); Height: 94.5 in (2400 mm); Depth: 185 in (4700 mm)
Press weight
33,112 lb (15,000 kg)
Cloud connectivity
Via HP PrintOSX
HP INDIGO ELECTROINKS
Standard 4-color printing
Cyan, Magenta, Yellow, and Black
Additional process inks
White, Premium White
HP IndiChrome 6-color printing
Cyan, Magenta, Yellow, Black, Orange, Violet, and Violet for packaging.
HP IndiChrome Plus 7-color printing
Cyan, Magenta, Yellow, Black, Orange, Violet, Violet for packaging, and Green
HP IndiChrome off-press spot inks
HP IndiChrome Ink Mixing Service for spot color creation using CMYK as well as Orange, Violet,
Green, Reflex Blue, Rhoda-mine Red, Bright Yellow, and Transparent
PANTONE® colors
Supports PANTONE PLUS®, PANTONE MATCHING SYSTEM®, and PANTONE Goe
HP Professional PANTONE Emulation Technology using CMYK on-press; HP IndiChrome on-press; HP IndiChrome Plus on-press; HP IndiChrome Ink Mixing Service for achieving up to 97% of the PANTONE® color range.
Enhanced Productivity Mode
Enables three-color EPM printing (Cyan, Magenta, Yellow)
OPTIONS
Reinsertion
Simplex and duplex
Extended inspection capabilities
Reverse Inspection Bridge (RIB) and low tension
Slitter
Optional kit for inline PS label slitting
Inspection
Automatic Alert Agent (AAA)
