Fast, easy to use, and safe to operate, the Roland DGSHAPE LD-300 laser decorator is a hot foil printing machine that personalizes poly carbonate, acrylic, and leather items with super-stylish metalized foil logos, designs, and text. Add stylish metallic logos, text and graphics directly onto items in minutes.
RequiredWorks with standard wall sockets - does not need large amounts of heat or pressure.
An included vise holds your objects perfectly in place and allows for quick set-up.
Use data files with different names and text to personalize products for different customers at-once.
A compact and clean machine that creates no dust or gas and fits in your office, studio, or home environment.
Import and edit a wide range of files in the included METAZAStudio software and get detailed text and image results with the LD-300.
Meet the experts and solve your most challenging jobs. Experience a live one-on-one demo tailored for you with our Application Engineers.
Imprintable material
Acrylic, ABS, PP, PS, PC, PU, PVC, Vegetable tanning Leather, Paper for Package (According to the condition).
Loadable material size
With table: 12.72 in. (W) x 10.51 in. (D) x 1.96 in. (H) [323 mm (W) x 267 mm (D) x 50 mm (H)]Must be flat material (Within ±0.5 mm from the Z detection position)
Without table: 11.06 in. (W) x 8.43 in. (D) x 8.5 in. (H) [281 mm (W) x 214 mm (D) x 216 mm (H)]Must be flat material (Within ±0.5 mm from the Z detection position)
Imprint area
Maximum: 12 in. (W) x 9.06 in. (D) x 1.57 in. (Z) [305 mm (W) × 230 mm (D) x 40 mm (Z)]
Recommended: 10.66 in.(W) x 7.56 in. (D) [271 mm (W) x 192 mm (D)]
Resolution
Default 353 dpi (text), 1058 dpi (vector)
Imprint direction
Unidirectional imprinting or bidirectional imprinting (Selectable with Windows driver)
Printing speed
Default: .95 in./s24 mm/s
Maximum: 1.89 in./s48 mm/s
Interface
USB
Power requirements
Dedicated AC adapter: AC 100 V ± 10 % 50/60 Hz
Machine: DC 19 V 1.2 A
Power consumption
23 W
Acoustic noise level
70 dB (A) or less
Operating temperature
10 ~ 30 °C
Operating humidity
35 ~ 80% (no condensation)
External dimensions
24.25 in. (W) × 23.11 in. (D) × 19.06 in. (H) [616 mm (W) × 587 mm (D) × 498 mm (H)]
Light source
For imprinting
Class 4 laser; wavelength: 450 nm; dispersion: 23 degrees; pulse width and repeatability: 167.5 μs, 4 kHz; max. output: 1.6 W
For positioning
Class 1 laser, wavelength: 655 nm
Safety devices Interlock
When the cover opens, the laser power supply turns off.
Cover
Light-blocking cover
Included items
AC adapter, power cord, USB cable, Software Package CD, setup guide, material retainer, film retainer (10 sheets), etc.
