Build a high-growth, profitable business by capturing a share of the growing need for short run jobs, delivered in fast turnaround time and enhanced with high-value features, including brand protection and mass customization, all while saving time and waste.
Meet the most stringent brand color and quality needs in each and every job you deliver, with newly introduced automated tools and HD Imaging System.
Adapt to changing market needs with one press that does the work of three. Expand your applications with the widest range of media and inksffer high-accuracy embellishment features, inline with the TRESU iCoat II 35K.
.jpg)
Produce dozens of jobs per day and up to 1 million B2 sheets per month, by leveraging new tools to increase print time by up to 40%Gain real production agility with drawers, a pallet feeder, and a proof tray on a B2 format.
Produce dozens of jobs per day and up to 1 million B2 sheets per month, by leveraging new tools to increase print time by up to 40%.2
Adapt to changing market needs with one press that does the work of three.
Meet the most stringent brand color and quality needs in each and every job you deliver, with newly introduced automated tools and HD Imaging System.
Meet the experts and solve your most challenging jobs. Experience a live one-on-one demo tailored for you with our Application Engineers.
TECHNICAL SPECIFICATIONS
Printing speed
3450 sheets per hour 4/0; 4600 sheets per hour in EPM
Image resolution 812 dpi addressability (virtual 2438 x 2438 dpi)
Line screens
175, 180, 180m, 190EPM, HMF-200
Sheet size
29.5 in x 20.9 in (750 X 530 mm ) maximum
Image size
29.1 x 20.1 in (740 x 510 mm) maximum
Substrate thickness
Paperboard and metallised boards 6 to 10 pt (140-250 microns); PVC and Polypropylene
up to 25 pt (630 microns); PET up to 16 pt (400 microns)
Substrate type
Paperboard, including C1S and C2S, virgin, recycled and metallised.
Optional support for synthetics.
Substrate weight
Paperboard and metallised boards 150 to 450 gsm; PVC up to 880 gsm; Polypropylene up to 630 gsm; PET up to 550 gsm
Feeder
Palette feeder: Up to 33.4 in or 1100 lb (85 cm or 500 Kg) of media.
Drawer feeder: two drawers, with 11.8 in (30 cm) of media.
Stacker
25.2 in (64 cm) of media
Print server
HP Production Pro for Indigo Labels & Packaging
Press dimensions
Length: 11,500 mm; Width: 433 in (4700 mm); Height: 94 in (2400 mm); Depth: 185 in
Press weight
28,600 lb (13,000 kg)
Cloud connectivity
Via HP PrintOSX
HP INDIGO ELECTROINKS
Standard 4-color printing
Cyan, Magenta, Yellow, and Black
5-color printing
Cyan, Magenta, Yellow, Black, and White
HP IndiChrome 6-color printing
Cyan, Magenta, Yellow, Black, Orange, Violet, and Violet for packaging
HP IndiChrome Plus 7-color printing
Cyan, Magenta, Yellow, Black, Orange, Violet, Violet for packaging and Green
HP IndiChrome off-press spot inks
HP IndiChrome Ink Mixing Service for spot color creation using CMYK as well as Orange, Violet, Green, Reflex Blue, Rhodamine Red, Bright Yellow, and Transparent
PANTONE® colors
Supports PANTONE PLUS®, PANTONE MATCHING SYSTEM®, and PANTONE Goe™
HP Professional PANTONE Emulation Technology using CMYK on-press; HP IndiChrome on-press; HP IndiChrome Plus on-press; HP IndiChrome off-press (IMS) Ink Mixing Service for achieving up to 97% of the PANTONE® color range.
OPTIONS
Synthetic Kit
Print on synthetics. Includes corona unit for refreshment treatment
Reinsertion Kit
Enables double-sided printing with accurate reinsertion
Inline Coater Adaptor
Interface between press and inline coater
HD Imaging Resolution: 1625 dpi address-ability (virtual 4876 x 4876 dpi)
Fine Line RIP
1600 dpi RIP for HD Imaging
Advanced Automatic Alert Agent
Updated inline quality control system with full page and single box eject
Enhanced Productivity Mode
Enables three-color EPM printing (Cyan, Magenta, Yellow)
