Kornit Allegro is a fastest, most cost-effective way to start printing on textile.One-step production line, enabling the shortest printing cycle, from file preparation to finished printed fabric with only a few minutes from file to finished fabric, and a sustainable process.
.jpg)
Our NeoPigment™ process eliminates the need for external process steps, making the Kornit Allegro a true standalone solution. Achieve the best results from PFP to finished printed fabric in the shortest cycle time possible.
Digitally print on a wide variety of fabrics with just one printer and one NeoPigment™ ink set. Enjoy excellenthand-feel and vivid color combinations on all fabric types.
By eliminating energy and water consuming steps, and using our 100% biodegradable inks, you benefit fromthe most eco-friendly solution in the textile printing industry.
.jpeg)
Meet the experts and solve your most challenging jobs. Experience a live one-on-one demo tailored for you with our Application Engineers.
PRINTING
Print Heads
Spectra Polaris
Print Heads Configuration
64 Heads, 7 colors + Inline ink fixation agent
Printing Resolution
400 - 1200 dpi
Printing Speed
300 m2/hr in high speed mode
Max Printing Width
180 cm / 70.8 in
NEOPIGMENT INK
Ink Type
Kornit's water - based NeoPigment Ink + Inline fixation agent
Ink Colors
Cyan, Magenta, Yellow, Black, Red, Green, Gray
Compatible Media
Fabric Types
Woven / Knitted / Non - Woven
Fiber Types
Naturals: Cotton, Linen, Viscose and more
Synthetics: Polyester, Nylon and more
Protein based: Silk, Wool and more
Blends: 50/50 Cotton/Polyester and more
Media Transportation
High precision adhesive belt conveyor system
Fabric Feeding System
Axial unwinding system with adjustable fabric width and tension mechanisms
Max Media Thickness
15 mm / 0.59 in
Max Roll Width
180 cm / 70.8 in
Max Roll Outer Diameter
40 cm / 15.74 in
Max Roll Weight
50 kg / 110.2 lb
Technical Specification
Power Supply
110/220V, 60/50 Hz 40A, 3Ph+N+GND 25 kW
Compressed Air
6-8 bar / ≤ 0.4 m3/min
Dimensions (W x D x H) Printer Only
460 x 203 x 214 cm / 181 x 80 x 84 in
Dimensions (W x D x H) Entire Solution
460 x 699 x 214 cm / 181 x 275 x 84 in(including loader, unloader and dryer)
Weight
3500kg / 7716.17lb
Dryer
Dryer Type
Allegro Triple Pass Air-Blow Dryer(Electric or gas versions available)
Dimensions (W x D x H)
283 x 226 x 192 cm / 111.4 x 89 x 75.6 in
Weight
1520kg / 3351lb
