Print

Printing modes

517 ft²/hr (48 m²/hr)- Billboard (2 pass)

174 ft²/hr (16 m²/hr)- Outdoor Plus (6 pass)

129 ft²/hr (12 m²/hr)- Indoor Quality (8 pass)

108 ft²/hr (10 m²/hr)- Indoor High Quality (10 pass)

65 ft²/hr (6 m²/hr)- Backlits, Textiles, and Canvas (16 pass)

54 ft²/hr (5 m²/hr)- High Saturation Textiles (20 pass)

Print resolution

Up to 1200 x 1200 dpi

Ink types

Water-based HP Latex Inks

Ink cartridges

7 (black, cyan, light cyan, light magenta, magenta, yellow, HP Latex Optimizer)

Cartridge size

775 ml Print heads 6 (2 cyan/black, 2 magenta/yellow, 1 light cyan/light magenta, 1 HP Latex Optimizer)

Long-term print-to-print repeatability

Average ≤ 1 dE2000, 95% of colors ≤ 2 dE2000

Media

Handling

Roll feed, take-up reel (optional), automatic cutter (for vinyl, paper-based media, backlit polyester film)

Media types

Banners, self-adhesive vinyls, films, papers, wall coverings, canvas, synthetics, (fabrics, mesh, textiles, and any other porous materials require a liner)

Roll size

10 to 54-in (254 to 1371-mm) rolls; 23 to 54-in (580 to 1371-mm) rolls with full support

Roll weight

55 lb (25 kg)

Roll diameter

7.1 in (180 mm)

Thickness

Up to 19.7 mil (Up to 0.5 mm)

Applications

Banners; Displays; Exhibition and event graphics; Exterior signage; Indoor posters; Interior decoration; Light boxes -film; Light boxes - paper; POP/POS; Posters; Vehicle graphics; Customizable clothing; Floor graphics; Labels and stickers; Wall decals; Window graphics.

Connectivity

Interfaces

Printer: Gigabit Ethernet (1000Base-T); Cutter: USB and Ethernet (LAN)

Dimensions (w x d x h)

Printer Printer: 91 x 33 x 54 in (2307 x 840 x 1380 mm); Cutter: 69 x 27 x 45 in (1750 x 680 x 1145 mm)

Shipping

Printer: 100 x 30 x 50 in (2541 x 760 x 1250 mm); Cutter: 74 x 19 x 27 in (1880 x 480 x 670 mm)

Weight

Printer

Printer: 384 lb (174 kg); Cutter: 106 lb (48 kg)

Shipping

Printer: 568 lb (258 kg); Cutter: 152 lb (69 kg)

What's in the box

Printer: HP Latex 315 Printer, print heads, maintenance cartridge, printer stand, spindle, user maintenance kit, edge holders, quick reference guide, setup poster, power cords; Cutter: HP Latex 54 Cutter, cutter stand, media basket, HPFlexiPrint and Cut RIP, HP Cutter Control software, quick reference guide, setup poster, documentation software,power cords, standard holder (1), standard blades (2), cut-off knife (1), 3-in media flanges (set of 2)

Environmental ranges

Operating temperature

Printer: 59 to 86ºF (15 to 30ºC); Cutter: 59 to 95ºF (15 to 35ºC)

Operating humidity

Printer: 20 to 80% RH (non-condensing); Cutter: 35 to 75% RH (non-condensing)

Acoustics

Sound pressure

Printer: 54 dB(A) (operating), 38 dB(A) (idle), <15 dB(A) (sleep); Cutter: 56 dB(A) (operating)

Sound power

Printer: 7.2 B(A) (operating), 5.5 B(A) (idle), <3.5 B(A) (sleep); Cutter: 7.0 B(A) (operating)

Power

Consumption

Printer: 2.2 kW (printing), 70 W (ready), <2.5 W (sleep); Cutter: 31 W (working mode)

Requirements

Printer: Input voltage (auto ranging) 200-240 V two wires and PE; 50/60 Hz; two power cords; 3 A max per printer power cord; 13 A max per curing power cord; Cutter: AC 100-240 V; 50/60 Hz, 85 VA max

Certification

Safety

Printer: IEC 60950-1+A1+A2 compliant; USA and Canada (CSA listed)Electromagnetic Printer: Compliant with Class A requirements, including: USA (FCC rules), Canada (ICES)

Environmental

Printer: ENERGY STAR; WEEE; REACH; EPEAT Bronze; OSHA; CE marking compliant

Warranty

Printer: 1 year limited hardware warranty; Cutter: 1 year provided that the HP Latex End of Installation Registration is completed by an HP authorized reseller.
