Roland BN-20A Desktop Inkjet Print and Cut Machine

Start building a t-shirt, poster, sticker, and decal graphics printing business, all from the comfort a desktop with the VersaSTUDIO BN-20 t shirt graphic printing & cutting machine, can print, cut, and create super high-quality graphics without the super high price tag.

Features & Benefits

Easily the most versatile print devices in their class— print and cut on a huge range of vinyl, films, and media.

Used by everyone from hobbyists who are looking to take their home business to the next level, to graphic design professionals who need quality and versatility from a desktop device to businesses that want to create custom graphics from their stores.

Legendary Roland DG machine reliability combines with exceptional image quality and color to give the solution to succeed

Productivity Features

Print and Cut in One Integrated Workflow

The BN-20 features a new cutting carriage design that does not bounce against the media if the cutting force is set too high for the substrate.

No Roland Has Ever Been Easier to Use

The BN-20 is the easiest to use of any device in the Roland printer lineup. All functionality of the device is handled through the VersaStudio utility software.

Bundled Design Software

The VersaStudio comes complete with R-Works, an entry-level design package created by Roland.

VersaWorks Professional RIP Software

Developed exclusively for Roland inkjet printers and printer/cutters, VersaWorks RIP software ensures exceptional production output with unmatched ease of use.

Shipping and Support

All printers will also require freight delivery and insurance too. Please contact your USCutter representative for details and added cost quotes for these services, as they vary depending on your location and needs.‍


A dark blue trenchcoat, blue shoes,
ISO 9001
1 year
Norde Support

Experience demo and real-time print samples.

Meet the experts and solve your most challenging jobs. Experience a live one-on-one demo tailored for you with our Application Engineers.

[additional information]


Width: 10.2 to 64 in. (259 to 1625 mm)

Thickness: Maximum 39 mil (1.0 mm) with liner

Roll diameter: Maximum 8.3 in (210 mm)

Roll weight: Maximum 88 lbs. (40 kg)

Core diameter : 3 in (76.2 mm) or 2 in (50.8 mm)

Printing Width

Max. 63.6 in. (1615 mm)

Ink cartridges

Type: Roland Eco-Sol MAX 2 INK

Capacity: 440 cc Colors Four Colors (cyan, magenta, yellow, and black)

Print resolution

Dots per in o Maximum 1,440 dpi

Print -Modes - Resolution - Pass - Speed

Max Speed (Banner) - 360x360 - 1 - 521 sqft/hr (49 m2/h)

Billboard (Banner) - 360x720 - 2 -289 sqft/hr (27 m2/h)

High Speed (Banner) - 360x720 - 3 - 194 sqft/hr (18 m2/h)

Standard (Banner) - 720x720 - 5 - 141 sqft/hr (13 m2/h)

High Quality (Banner) - 1440x720 - 6 - 63 sqft/hr (6 m2/h)

High Speed (Vinyl) - 360x720 - 3 - 199 sqft/hr (19 m2/h)

Standard (Vinyl) - 540x720 - 5 - 141 sqft/h (13m2/h)720 x 7206117 sqft/hr (11m2/h)

High Quality (Vinyl) - 1440x720 - 847 sqft/hr (4 m2/h)

Distance accuracy

Error of less than ±0.3percent of distance traveled, or ±0.3 mm, whichever is greater

Media heating system

Print heater - Setting range for the preset temperature: 30 to 45¼C (86 to 112¼F)

Dryer Setting - range for the preset temperature: 30 to 50¼C (86 to 122¼F)


Ethernet (10BASE-T/100BASE-TX, automatic switching)

Power-saving function

Automatic sleep feature

Power requirements

AC 100 to 120 V ±10 percent, 8.2A, 50/60 Hz orAC 220 to 240 V ±10percent, 4.2A, 50/60 Hz

Power consumption

During operation:Approx. 1,070 W

Sleep mode: Approx. 14.5 W

Acoustic noise level

During operation: 64 dB (A) or less

During standby: 41 dB (A) or less

Dimensions (with stand)

101.4 (W) x 31.3 (D) x 50 (H) in (2,575 (W) x 795 (D) x 1,270 (H) mm)

Weight (with stand)

308.6 lbs. (140 kg)

Included items

Stand, power cord,  media clamps, media holder, replacement sheet cutting blade, software RIP, user's manual, etc.
